| Principle
Of Supersonic Cleaning
|
|
A supersonic
wave of 43,000 cycles per second is generated through
the cleansing liquid. The action of this longitudinal
wave causes dielectric pressure to build up, resulting
in numerous micro-vacuum bubbles producing the effect
of cavitation. When these bubbles explode, the force of
their explosion removes the encrusted dirt, grime of other
understable substance, even in tiny, hard-to-reach corners.
Its efficiency is remarkable.
|
|
Spectacles, toothbrushes, pendants, glass items, dentures,
razor blades, machine nozzles, jewelery, diamonds, gold
objects, signature chops, watch parts, baby bottles ....
etc.
|
| INTERNAL
TANK SIZE |
104
x 48 mm |
| EXTERNAL
DIMENSION |
140
x 148 x 200 M/M
|
| CAPACITY
OF CONTAINER |
400 (ML)
|
| MATERIAL |
INTERNAL
TANK: Staninless Steel SUS304
EXTERNAL BODY: ABS With Fireproof
COVER: Semi Transparent PS Plastic
|
| OUTPUT
FREQUENCY |
43 KHz
|
| TIMER
SETTING |
3/5 Minutes
|
| POWER
DISSPATION |
50 W
|
| POWER
SWITCH |
On/Off
Touch Operated Switch Tank With Basket To Clean Easily
|
| POWER
SUPPLY |
AC 100~120V
50/60Hz |
| MEASUREMENT |
10Pcs/Carton/2.3Cuft.
|
| NET/GROSS
WEIGHT |
10Pcs/Carton/N.W.9Kgs/G.W.12.5Kgs
|
|
| Four
Great Features Of This Product:
|
| 1. |
Auto
wave-seeking system design, stable power, easy to operate.
|
| 2. |
Wide
angle shooting area, never damage your materials.
|
| 3. |
Professional
technology, self-developed the most advanced electric
circuit design, even you carelessly start the machine
without cleaning liquid, it also doesn't harm the machine.
|
| 4. |
Self-developed
and manufactured, technology is 100% transferred. We also
offer one year free service after the machines are sold.
|
| SPECIFICATIONS |
SFU-150
U.3 Table-Top Type Ultrasonic Cleaner Machine
|
| INTERNAL
TANK SIZE |
L300 X
W150 X H100 M/M
|
| EXTERNAL
DIMENSION |
L310 X
W170 X H210 M/M
|
| MATERIAL |
INTERNAL
TANK & EXTERNAL BODY: Staninless Steel SUS304
|
| COVER |
Material:
Staninless Steel SUS304
|
| CAPACITY
OF CONTAINER |
4.5L
|
| OUTPUT
FREQUENCY |
38~43KHz
|
| POWER
DISSPATION |
150W (Max.)
|
| POWER
SUPPLY |
AC 110V
50Hz or AC220V 60Hz
|
| TIMER
SETTING |
0~15Min/0~30Min
±0.5Min
|
SUGGESTIONS
OF
ADDITIONAL EQUIPMENTS |
1. Cleaning
Basket: 260x120x70m/m(#style at the bottom)
2. Clean Liquid
|
|
Able to clean wide-range items such as Medical pharmaceutical
laboratory appliances, glass products, waterproof instruments,
jewelerys, optical lens, hardware accessories, dining
appliances, electronic parts ... etc.
|
|
7F,
No. 12, Lane 181, Chia Hsing St., Taipei City, Taiwan,
R.O.C.
TEL:886-2-27323913 FAX:886-2-27366333
http://www.sonic.com.tw
|
